The SRNE EOS Series SR-EOS15B is a 16.07 kWh lithium iron phosphate (LiFePO₄) battery designed for residential energy storage. Below are its key specifications:

Electrical Specifications:

• Rated Voltage: 51.2 V
• Rated Capacity: 314 Ah
• Battery Power: 16.07 kWh
• Battery Type: LiFePO₄ (LFP)
• Max. Charging Voltage: 57.6 V
• Over-Discharging Voltage: 44.8 V
• Max. Charging Current: 200 A
• Peak Charging Current: 220 A (for 3 seconds)
• Max. Discharging Current: 200 A
• Peak Discharging Current: 220 A (for 3 seconds)
• Breaker Current: 240 A

Performance and Lifespan:

• Cycling Lifespan: 8,000 cycles at 80% Depth of Discharge (DoD), 0.5C rate, 25 °C
• Lifetime: Approximately 20 years

Scalability:

• Max. Parallel Capacity: Up to 16 units, expandable to 256 kWh

Physical Specifications:

• Weight: 123 kg (271 lb)
• Dimensions (L×W×H): 1,075 mm × 460 mm × 271 mm (3.53 ft × 1.51 ft × 0.89 ft)

Communication and Monitoring:

• Interfaces: CAN, RS485, USB, WiFi, Bluetooth
• Features: Large LCD screen for real-time data; supports monitoring via app

Environmental Specifications:

• Operating Temperature Range:
  • Charging: 0 °C to 45 °C (32 °F to 113 °F)
  • Discharging: -10 °C to 45 °C (14 °F to 113 °F)
• Storage Conditions:
  • 6 months at 25 °C
  • 3 months at 35 °C
  • 1 month at 45 °C

Protection and Safety:

• Cooling Method: Natural cooling
• Protection Grade: IP65
• Safety Features: High-quality LFP cells; secondary breaker protection

Installation:

• Mounting Options: Supports wall or floor mounting; plug-and-play design with wiring accessible from either side

This battery is compatible with various inverter brands and supports up to 16 units in parallel, allowing for significant scalability in energy storage solutions.
